DTH drilling hammer

OVERVIEW：

DTH drilling hammer are widely used in mining, water well drilling, geotechnical industries,etc.Price:500USD-3000USD

We're here to help:

Easy ways to get the answers you need.

Leave Message

FEATURES

DTH drilling hammer are widely used in different drilling applications including mining,quarrying, water well drilling, geotechnical industries and etc.
Price:500USD-3000USD

1.Optimized and robust desigh

2.superior material

3.longer life

4.less air consumption

5.15% higher penetration speed than conventional DTH hammer in the market.

TECHNICAL DATA

Hammers	Connection Thread	Suitable bit	Working pressure	Air consumption
4" hammers	API 2 3/8"Reg	105-130mm	1.0-2.5Mpa	1.0 Mpa	6 m3/min
				1.8 Mpa	10 m3/min
				2.4 Mpa	15 m3/min
5" hammers	API 2 3/8"Reg	130-156mm	1.0-2.5Mpa	1.0 Mpa	9 m3/min
	API 3 1/2"Reg			1.8 Mpa	15 m3/min
				2.4 Mpa	23 m3/min
6" hammers	API 3 1/2"Reg	152-203mm	1.0-2.5Mpa	1.0 Mpa	10 m3/min
				1.8 Mpa	20 m3/min
				2.4 Mpa	28.5 m3/min
8" hammers	API 4 1/2"Reg	200-279mm	1.0-2.5Mpa	1.0Mpa	15m3/min
				1.8Mpa	26m3/min
				2.4Mpa	34m3/min
10" hammers	API 6 5/8"Reg	254-330mm	1.0-2.5Mpa	1.0Mpa	22m3/min
				1.8Mpa	40m3/min
				2.4Mpa	55m3/min
12" hammers	API 6 5/8"Reg	305-381mm	1.0-2.5Mpa	1.0Mpa	30m3/min
				1.8Mpa	56m3/min
				2.4Mpa	78m3/min
