PDC drilling bit

OVERVIEW:

PDC Bit is a full-scale drilling bit, mainly be used in construction ,mining, geology, coal etc. Price:100USD-400USD

We're here to help:

Easy ways to get the answers you need.

Leave Message

FEATURES

PDC Bit is a full-scale drilling bit, mainly be used in construction ,mining, geology, coal, water conservancy and hydropower, highway, high speed railway and bridge etc.
Price:100USD-400USD


1. High drilling efficiency: PDC water well drill bits have a high drilling speed due to their sharp and durable polycrystalline diamond compact (PDC) cutters.

2. Long service life: The PDC cutters on the drill bits are made of synthetic diamond materials, which have excellent wear resistance and can withstand the harsh drilling conditions for a long time.

3. Good stability: PDC water well drill bits have good stability during drilling, which ensures smooth and accurate drilling operations.

4. Versatility: PDC water well drill bits can be used for various drilling applications, including soft to medium-hard formations, making them suitable for a wide range of water well drilling projects.

5. Cost-effective: PDC water well drill bits offer a cost-effective solution for water well drilling due to their long service life and high drilling efficiency, reducing the overall drilling costs.

TECHNICAL DATA
line numberSpecification
(mm)
Drilling procedure parameters
Drill pressureRotating speedpump volume
128300-700kg300-350rpm150-200/min
230300-700kg300-350rpm150-200/min
332300-700kg300-350rpm150-200/min
448300-700kg300-350rpm120-160/min
556320-800kg250-350rpm130-180/min
675480-1200kg200-300rpm150-200/min
794640-1600kg150-250rpm200-250/min
8110880-2200kg120-200rpm200-300min
91521500-3000kg100-200rpm500-850/min
101901800-4000kg100-200rpm600-1200/min
112302200-4500kg100-120rpm750-1400/min
122702400-5000kg100-120rpm1000-1500/min
